ST NUCLEO-L433RC-P User Manual

Connectors UM2206
34/55 UM2206 Rev 3
10.2 Arduino Uno V3 connectors
The Arduino connectors CN7, CN8 CN9 and CN10 (see Figure 15) are female connectors
compatible with Arduino standard. Most shields designed for Arduino can fit to the STM32
Nucleo-64-P board.
The Arduino connectors on STM32 Nucleo-64-P board support the Arduino Uno V3.
Figure 15. Arduino connectors
The related pinout for Arduino connector is showed in Figure 16 and listed in Table 14.
Arduino_D[8..15]: CN7
Arduino_D[0..7]: CN9
Arduino_A[0..5]: CN10
Arduino_PWR: CN8
