UM2206 Rev 3 41/55
UM2206 NUCLEO-L412RB-P, NUCLEO-L433RC-P and NUCLEO-L452RE-P I/O assignment
54
31 V
SS
GND PWR GND
32 V
DD
V
DD_MCU
PWR V
DD_MCU
1.8 V / 3.3 V
33 PB12 PB12 I/O
34 PB13 PB13 ARD_D13 - SPI2_SCK / LED / IO
35 PB14 PB14 ARD_D12 - SPI2_MISO / IO
36 PB15 PB15
ARD_D11 - SPI2_MOSI - TIM15_CH2 /
I/O
37 PC6 PC6 I/O
38 PC7 PC7 ARD_D7 / IO
39 PC8 PC8 I/O
40 PC9 PC9 I/O
41 PA8 PA8 ARD_D9 -TIM1_CH1 / IO
42 PA9 UART1_TX ARD_D1_TX / STLINK_TX
43 PA10 UART1_RX ARD_D0_RX / STLINK_RX
44 PA11 PA11 ARD_D10 -TIM1_CH4 - SPIx-CS / IO
45 PA12 PA12 ARD_D2 / IO
46 PA13 PA13 TMS_SWDIO
47 V
SSUSB
GND PWR GND
48 V
DDUSB
V
DD_MCU
/ V
DD
PWR V
DD_MCU
1.8 V / 3.3 V
49 PA14 PA14 TCK_SWCLK
50 PA15 PA15 ARD_D5 - TIM2_CH1 / IO
51 PC10 PC10 I/O
52 PC11 PC11 I/O
53 PC12 PC12 I/O
54 PB3 PB3 ARD_D3 - TIM2_CH2 / SWO
55 PB4 PB4 I/O
56 PB5 PB5 ARD_D4 / IT5
57 PB6 PB6 ARD_D8 / IO
58 PB7 PB7 ARD_D14 - I2C1_SDA / IO
59 PH3-BOOT0 BOOT0 BOOT0
60 PB8 PB8 ARD_D15 - I2C1_SCL / IO
61 PB9 PB9 I/O
62 V
DD1V2
V
DD12
PWR ExtSMPS 1.1 V
Table 16. NUCLEO-L412RB-P, NUCLEO-L433RC-P and NUCLEO-L452RE-P
I/O assignment (continued)
Pin
No.
Pin name Signal or label Main feature / optional feature (SB)
