ST STM32F030 User Manual

Connecting modules on the prototyping board UM1658
26/39 DocID025097 Rev 1
Table 7. Connecting using IDC10
Mikroelektronica IDC10 connector 32F0308DISCOVERY
P0 GPIO PC0 GPIO OUTPUT (3.3V tolerant)
P1 GPIO PC1 GPIO OUTPUT (3.3V tolerant)
P2 GPIO PC2 GPIO OUTPUT (3.3V tolerant)
P3 GPIO PC3 GPIO OUTPUT (3.3V tolerant)
P4 GPIO PC4 GPIO OUTPUT (3.3V tolerant)
P5 GPIO PC5 GPIO OUTPUT (3.3V tolerant)
P6 GPIO PC6 GPIO OUTPUT (5V tolerant)
P7 GPIO PC7 GPIO OUTPUT (5V tolerant)
VCC VCC 5V power line 3V VDD
GND Reference Ground GND VSS
P0 GPIO PC0 GPIO OUTPUT (3.3V tolerant)
P1 GPIO PC1 GPIO OUTPUT (3.3V tolerant)
P2 GPIO PC2 GPIO OUTPUT (3.3V tolerant)
P3 GPIO PC3 GPIO OUTPUT (3.3V tolerant)
