DocID025097 Rev 1 31/39
UM1658 Connecting modules on the prototyping board
38
Note: For an up-to-date list, visit http://www.st.com/internet/evalboard/subclass/1116.jsp. The
DIL24 boards are described as “adapter boards” in the field “General Description”.
5.3 Arduino shield boards
Arduino™ is an open-source electronics prototyping platform based on flexible, easy-to-use
hardware and software. See http://www.arduino.cc for more information.
Arduino accessory boards are called “Shields” and can be easily connected to the
32F0308DISCOVERY according to the following table.
STEVAL-MKI124V1
10AXISMODULE [LSM303DLHC + L3GD20+
LPS331AP]
STEVAL-MKI125V1 A3G4250D
Table 9. Supported MEMS adapter boards (continued)
ST MEMS DIL24 Eval Board Core product
Table 10. Connecting with Arduino shields
Arduino power connector 32F0308DISCOVERY
Reset Reset from Shield board NRST Reset discovery
3V3 VCC 3.3V power line 3V VDD
5V VCC 5V power line 5V VDD
GND Reference Ground GND Reference Ground
GND Reference Ground GND Reference Ground
Vin External alimentation 3 V
Jumper fitted to power board by
External 3 V power supply.
Arduino analog in connector 32F0308DISCOVERY
A0 Analog input or Digital pin 14 PC0 ADC_IN10
A1 Analog input or Digital pin 15 PC1 ADC_IN11
A2 Analog input or Digital pin 16 PC2 ADC_IN12
A3 Analog input or Digital pin 17 PC3 ADC_IN13
A4
Analog input or SDA or Digital
pin 18
PC4 or PF7 ADC_IN14 or I2C2_SDA
A5
Analog input or SCL or Digital
pin 19
PC5 or PF6 ADC_IN15 or I2C2_SCL
