DocID025097 Rev 1
9/39
UM1658
Hardware and layout
38
Figure 3. T
op layout
Note:
Pin 1 of CN2, CN3, P1
and P2 connectors are identified by a square.
(red/green LED) LD2
COM
CN3
SWD connector
IDD measurement
ST
-LINK/V2
B1 user button
B2 reset button
LD1 (red LED)
PWR
CN2
ST
-LINK/DISCO
VER
Y
selector
(green LED) LD3
LD4 (blue LED)
STM32F030R8T6
JP2
5V power supply
input output
3V power supply
input output
SB1 (VDD)
SB3 (B1-USER)
SB4 (B2-RESET)
MS31936V1
MB1134 revA
STM32F0308-DISCO
8
10
