3 Features
The STM32F0DISCOVERY kit offers the following features:
● STM32F051R8T6 microcontroller featuring 64 KB Flash, 8 KB RAM in an LQFP64
package
● On-board ST-LINK/V2 with selection mode switch to use the kit as a standalone
ST-LINK/V2 (with SWD connector for programming and debugging)
● Board power supply: through USB bus or from an external 5 V supply voltage
● External application power supply: 3 V and 5 V
● Four LEDs:
– LD1 (red) for 3.3 V power on
– LD2 (red/green) for USB communication
– LD3 (green) for PC9 output
– LD4 (blue) for PC8 output
● Two push buttons (user and reset)
● Extension header for LQFP64 I/Os for quick connection to prototyping board and easy
probing.
● An additional board is provided with the kit which can be connected to the extension
connector for even easier prototyping and probing.
● A large number of free ready-to-run application firmware examples are available on
www.st.com/stm32f0discovery to support quick evaluation and development.
