UM1525 Connecting modules on the prototyping board
Doc ID 022910 Rev 2 27/41
5 Connecting modules on the prototyping board
This section gives some examples of how to connect ready-to-use modules available from
different manufacturers to the STM32F0DISCOVERY kit via the prototyping board included
in the kit.
Software examples, based on the connections described below, are available at
www.st.com/stm32f
0discovery.
5.1 Mikroelektronica accessory boards
Mikroelektronika, http://www.mikroe.com, has specified two standard connectors for their
accessory boards, named mikroBUS™ (http://www.mikroe.com/mikrobus_specs.pdf) and
IDC10.
MikroBUS™ is a 16-pin connector to connect acce
ssory boards very quickly and easily to a
microcontroller board through SPI, USART or I2C communications, along with additional
pins such as Analog Input, PWM and Interrupt.
The set of mikroElektronika boards compatib
le with mikroBUS™ is called “Click boards”.
IDC10 is a 10-pin connector to connect the general purpose I/O of an MCU to other
ac
cessory boards.
The tables below are one solution for connecting mikroBUS™ and IDC boards to the
STM32F0DISCOVERY; this solution used in th
e different examples is available at
www.st.com/stm32f
0discovery.
Table 7. Connecting using mikroBUS™
Mikroelektronica mikroBUS™ STM32F0DISCOVERY
Pin Description Pin Description
AN Analog pin PA 4 DAC1_OUT
RST Reset pin PB13 GPIO OUTPUT (5V tolerant)
CS SPI Chip Select line PA 11 GPIO OUTPUT (5V tolerant)
SCK SPI Clock line PB3 SPI1_SCK
MISO SPI Slave Output line PB4 SPI1_MISO
MOSI SPI Slave Input line PB5 SPI1_MOSI
PWM PWM output line PA 8 TIM1_CH1
INT Hardware Interrupt line PB12 GPIO INPUT EXTI (5V tolerant)
RX UART Receive line PA 3 USART2_RX
TX UART Transmit line PA 2 USART2_TX
SCL I2C Clock line PF6 I2C2_SCL
SDA I2C Data line PF7 I2C2_SDA
5V VCC 5V power line 5V Power line
