Conventions UM1525
6/41 Doc ID 022910 Rev 2
1 Conventions
Tabl e 2 provides the definition of some conventions used in the present document.
Table 2. ON/OFF conventions
Convention Definition
Jumper JP1 ON Jumper fitted
Jumper JP1 OFF Jumper not fitted
Solder bridge SBx ON SBx connections closed by solder
Solder bridge SBx OFF SBx connections left open
