ST STM32F0DISCOVERY

Hardware and layout UM1525
10/41 Doc ID 022910 Rev 2
Figure 3. Top layout
MS30024V1
(red/green LED) LD2
COM
CN3
SWD connector
IDD measurement
ST-LINK/V2
B1 user button
B2 reset button
LD1 (red LED)
PWR
CN2
ST-LINK/DISCOVERY
selector
(green LED) LD3
LD4 (blue LED)
STM32F051R8T6
JP2
5V power supply
input output
3V power supply
input output
SB1 (VBAT)
SB3 (B1-USER)
SB4 (B2-RESET)
Note: Pin 1 of CN2, CN3, P1 and P2 connectors are identified by a square.
