ST STM32F0DISCOVERY

UM1525 Hardware and layout
Doc ID 022910 Rev 2 11/41
Figure 4. Bottom layout
SB6, SB8, SB10, SB12
MS30025V1
SB5, SB7, SB9, SB11
(RESERVED)
(DEFAULT)
SB20, SB21 (X3 crystal)
SB14, SB15 (RX, TX)
SB19 (NRST)
SB16, SB17 (X2 crystal)
SB13 (STM_RST)
SB22 (T_SWO)
SB18 (MCO)
