ST STM32F103RET6 - Table 4. Returned Values for *Start Command

Specifically, bit#0 of the “BT” data corresponds to the status of the SW1 button on the demonstration kit board: it
is set to 1 when the SW1 is pressed (otherwise 0). Bit#1 has the same behavior but is dedicated to the SW2.
Before sending the *start command, the device must be out from 3-state and some registers must be configured
according to user needs, therefore, *start must be preceded by a *zoff and some “Register Write” commands.
Table 4. Returned values for *start command shows the format of the string returned for each device when a *start
command is sent.
Table 4. Returned values for *start command
STEVAL # (Device) Returned value
STEVAL-MKI009V1 (LIS3LV02DL)
STEVAL-MKI089V1 (LIS331DLH
STEVAL-MKI092V1 (LIS331HH)
STEVAL-MKI105V1 (LIS3DH)
STEVAL-MKI107V2 (L3GD20)
STEVAL-MKI110V1 (AIS328DQ)
STEVAL-MKI125V1 (A3G4250D)
STEVAL-MKI134V1 (LIS3DSH)
STEVAL-MKI135V1 (LIS2DH)
STEVAL-MKI136V1 (L3GD20H)
STEVAL-MKI151V1 (LIS2DH12)
STEVAL-MKI153V1 (H3LIS331DL)
STEVAL-MKI158V1 (AIS3624DQ)
STEVAL-MKI164V1 (LIS2HH12)
STEVAL-MKI166V1 (H3LIS100DL)
STEVAL-MKI167V1 (H3LIS200DL)
STEVAL-MKI168V1 (IIS2DH)
STEVAL-MKI169V1 (I3G4250D)
STEVAL-MKI170V1 (IIS328DQ)
STEVAL-MKI179V1 (LIS2DW12)
STEVAL-MKI180V1 (LIS3DHH)
STEVAL-MKI186V1 (IIS3DHHC)
s t XH XL YH YL ZH ZL int1 int2 sw1|sw2 \\r \\n
STEVAL-MKI013V1 (LIS302DL)
STEVAL-MKI087V1 (LIS331DL)
STEVAL-MKI152V1 (LIS2DM)
STEVAL-MKI175V1 (LIS2DE12)
s t X Y Z int1 int2 sw1|sw2 \\r \\n
STEVAL-MKI176V1 (LSM6DS3H)
STEVAL-MKI178V1 (LSM6DSL)
STEVAL-MKI182V1 (ISM330DLC)
s t A_XH A_XL A_YH A_YL A_ZH A_ZL G_XH G_XL G_YH G_YL
G_ZH G_ZL STEP_L STEP_H int1_int2 sw1|sw2 \\r \\n
STEVAL-MKI015V1 (LIS344ALH)
STEVAL-MKI114V1 (MAG PROBE)
s t XH XL YH YL ZH ZL sw1|sw2 \\r \\n
STEVAL-MKI137V1 (LIS3MDL)
STEVAL-MKI181V1 (LIS2MDL)
STEVAL-MKI185V1 (IIS2MDC)
s t XH XL YH YL ZH ZL int1 sw1|sw2 \\r \\n
UM0979
Supported commands
UM0979 - Rev 6
page 15/39
