Table 5. Returned values for *debug command
STEVAL # (Device) Returned value
STEVAL-MKI009V1 (LIS3LV02DL)
STEVAL-MKI013V1 (LIS302DL)
STEVAL-MKI015V1 (LIS344ALH)
STEVAL-MKI087V1 (LIS331DL)
STEVAL-MKI089V1 (LIS331DLH)
STEVAL-MKI092V1 (LIS331HH)
STEVAL-MKI105V1 (LIS3DH)
STEVAL-MKI110V1 (AIS328DQ)
STEVAL-MKI134V1 (LIS3DSH)
STEVAL-MKI135V1 (LIS2DH)
STEVAL-MKI151V1 (LIS2DH12)
STEVAL-MKI152V1 (LIS2DM)
STEVAL-MKI153V1 (H3LIS331DL)
STEVAL-MKI158V1 (AIS3624DQ)
STEVAL-MKI164V1 (LIS2HH12)
STEVAL-MKI166V1 (H3LIS100DL)
STEVAL-MKI167V1 (H3LIS200DL)
STEVAL-MKI168V1 (IIS2DH)
STEVAL-MKI170V1 (IIS328DQ)
STEVAL-MKI175V1 (LIS2DE12)
X=XXXXX Y=YYYYY Z=ZZZZZ
STEVAL-MKI084V1 (LPY430AL)
STEVAL-MKI097V1 (LPR430AL)
STEVAL-MKI098V1 (LPR410AL)
VREF=VVVVV OUT1=XXXXX 4OUT1=XXXXX OUT3=YYYYY
OUT6=YYYYY
STEVAL-MKI075V1 (LY3100ALH) VREF=VVVVV OUT1=XXXXX 4OUT1=XXXXX
STEVAL-MKI106V1 (LSM303DLHC)
STEVAL-MKI113V1 (LSM303DLM)
STEVAL-MKI133V1 (LSM303D)
STEVAL-MKI163V1 (LSM303C)
STEVAL-MKI172V1 (LSM303AGR)
AX=XXXXX AY=YYYYY AZ=ZZZZZ MX=XXXXX MY=YYYYY
MZ=ZZZZZ
STEVAL-MKI114V1 (MAG PROBE)
STEVAL-MKI137V1 (LIS3MDL)
MX=XXXXX MY=YYYYY MZ=ZZZZZ
STEVAL-MKI107V2 (L3GD20)
STEVAL-MKI125V1 (A3G4250D)
STEVAL-MKI136V1 (L3GD20H)
STEVAL-MKI169V1 (I3G4250D)
P=PPPPP R=RRRRR Y=YYYYY
STEVAL-MKI108V2 (9AXISMODULEV2)
STEVAL-MKI154V1 (LSM9DS0)
STEVAL-MKI159V1 (LSM9DS1)
AX=XXXXX AY=YYYYY AZ=ZZZZZ MX=XXXXX MY=YYYYY
MZ=ZZZZZ GX=XXXXX GY=YYYYY GZ=ZZZZZ
UM0979
Supported commands
UM0979 - Rev 6
page 17/39
