ST STM32F103RET6 - Page 34

Designator Description Comment Footprint
R36 Resistor 1.5 kΩ 0805
R37 Resistor 22 Ω 0805
R38 Resistor 22 Ω 0805
R39 Resistor 47 kΩ 0805
SW1 SMT SWITCH
SW2 SMT SWITCH
SW3 SMT SWITCH
U1 TS924 TS924 TS924
U2 Component_1 lds3985xx30 SOT23-5
U3 TS924 TS924 TS924
U4 TS922 TS922 SO8_2
U5 USBLC6-2P6 USBLC6-2P6 SOT-666
U6 STM32F103RET6 LQF64
UM0979
Bill of materials
UM0979 - Rev 6
page 34/39
