Hardware layout and configuration UM1570
12/41 UM1570 Rev 7
Figure 3. Board layout (top view)
Note: A square identifies pin 1 of CN3, CN4, JP3, JP4, P1, and P2 connectors.
ST-LINK/V2
USB USER
Red PWR LED
(LD1)
Red/green COM LED
(LD2)
SWD connector
(CN3)
I
DD
measurement
(JP3)
User button
(B1)
ST-LINK/
STM32F3DISCOVERY
Selector
(CN4)
3 V Power
supply
input/output
Reset button
(B2)
L3GD20
LSM303DLHC
STM32F303VCT6
Red LED
(LD3)
Blue LED
(LD4)
Green LED
(LD6)
Orange LED
(LD8)
Orange LED
(LD5)
Green LED
(LD7)
Blue LED
(LD9)
Red LED
(LD10)
5 V Power
supply
input/output
