ST STM32F3DISCOVERY User Manual

Hardware layout and configuration UM1570
30/41 UM1570 Rev 7
PC12
TIM8_CH3N,
UART5_TX,
SPI3_MOSI/
I2S3_DOUT,
USART3_CK
80------------33
PC13 TIM1_CH1N
7------------10
PC14 OSC32_IN 8-------
OSC32_IN
----7
PC15 OSC32_OUT
9-------
OSC32_OUT
----8
PD0 CAN_RX
81------------34
PD1
TIM8_CH4_BKIN2,
CAN_TX
82------------31
PD2
TIM3_ETR,
TIM8_BKIN,
UART5__RX
83------------32
PD3
TIM2_CH1_ETR,
USART2_CTS
84------------29
PD4
TIM2_CH2,
USART2_RTS
85------------30
PD5 USRT2_TX 86------------27
PD6
TIM2_CH4,
USART2_RX
87------------28
PD7
TIM2_CH3,
USART2_CK
88------------25
Table 7. STM32F303VCT6 MCU pin description versus board function (continued)
(1)
MCU pin Board function
Main
function
Alternate function
LQFP100 pin number
VCP
LSM303DLHC or LSM303AGR
L3GD20 or I3G4250D
Push-button
LED
SWD
USB
OSC
Free I/O
Power supply
CN3
P1 P2
