DocID030511 Rev 1 43/69
UM2198 STM32H743I-EVAL I/O assignment
68
L2 PC0 ULPI_STP -
M2 PC1 RMII_MDC PDM1_D1
M3 PC2 DFSDM_CKOUT -
M4 PC3 DFSDM_DATA1 -
T4 PC4 RMII_RXD0 -
U4 PC5 RMII_RXD1 -
F14 PC6 SDIO_1_D0DIR -
F13 PC7 SDIO_1_D123DIR -
E13 PC8 SDIO_1_D0 -
E14 PC9 SDIO_1_D1 -
A13 PC10 SDIO_1_D2 -
B13 PC11 SDIO_1_D3 -
C12 PC12 SDIO_1_CK -
E3
PC13-
ANTI_TAMP
KEY_TAMP_1/WKUP2 -
C2
PC14-
OSC32_IN
OSC32_IN -
C1
PC15-
OSC32_OUT
OSC32_OUT -
D13 PD0 FMC_D2 -
E12 PD1 FMC_D3 -
D12 PD2 SDIO_1_CMD -
B12 PD3 GPIO_CAN_STANDBY -
A12 PD4 FMC_NOE -
A11 PD5 FMC_NWE -
B11 PD6 FMC_NWAIT -
C11 PD7 FMC_NE1 -
U16 PD8 FMC_D13 -
T17 PD9 FMC_D14 -
T16 PD10 FMC_D15 -
R15 PD11 FMC_A16 -
R16 PD12 FMC_A17 -
R17 PD13 FMC_A18 -
P16 PD14 FMC_D0 -
P15 PD15 FMC_D1 -
C4 PE0 FMC_NBL0 -
Table 33. STM32H743I-EVAL I/O assignment (continued)
Pin No. Pin Name Default function Alternative function
