STM32H743I-EVAL I/O assignment UM2198
44/69 DocID030511 Rev 1
B4 PE1 FMC_NBL1 -
C3 PE2 PDM1_CK1
FMC_A23/TRACECLK/
SAI_1_MCLK_A
D3 PE3 SAI1_SD_B FMC_A19/TRACED0
D2 PE4 SAI1_FS_A FMC_A20/TRACED1
D1 PE5 SAI1_SCK_A FMC_A21/TRACED2
E5 PE6 SAI1_SD_A FMC_A22/TRACED3
U9 PE7 FMC_D4 -
T9 PE8 FMC_D5 -
P9 PE9 FMC_D6 -
N9 PE10 FMC_D7 -
P10 PE11 FMC_D8 -
R10 PE12 FMC_D9 -
T10 PE13 FMC_D10 -
U10 PE14 FMC_D11 -
R11 PE15 FMC_D12 -
G4 PF0 FMC_A0 -
G3 PF1 FMC_A1 -
G1 PF2 FMC_A2 -
H4 PF3 FMC_A3 -
J5 PF4 FMC_A4 -
J4 PF5 FMC_A5 -
K2 PF6 QSPI_BK1_IO3 -
K3 PF7 QSPI_BK1_IO2 -
K4 PF8 QSPI_BK1_IO0 -
L4 PF9 QSPI_BK1_IO1 -
L3 PF10 LED1 -
T7 PF11 SDR_SDNRAS -
R7 PF12 FMC_A6 -
P7 PF13 FMC_A7 -
P8 PF14 FMC_A8 -
R9 PF15 FMC_A9 -
T8 PG0 FMC_A10 -
U8 PG1 FMC_A11 -
H16 PG2 FMC_A12 -
Table 33. STM32H743I-EVAL I/O assignment (continued)
Pin No. Pin Name Default function Alternative function
