DocID030511 Rev 1 45/69
UM2198 STM32H743I-EVAL I/O assignment
68
H15 PG3 FMC_A13 -
H14 PG4 FMC_A14 / SDR_BA0 -
G14 PG5 FMC_A15 / SDR_BA1 -
G15 PG6 QSPI_BK1_NCS -
F16 PG7 SAI_1_MCLK_A -
F15 PG8 SDR_SDCLK -
A10 PG9 QSPI_BK2_IO2 -
A9 PG10 FMC_NE3 -
B9 PG11 RMII_TX_EN -
C9 PG12 RMII_TXD1 -
D9 PG13 RMII_TXD0 -
D8 PG14 QSPI_BK2_IO3 -
D6 PG15 SDR_SDNCAS -
J2 PH0 - OSC_IN OSC_IN -
J1
PH1 -
OSC_OUT
OSC_OUT -
N2 PH2 QSPI_BK2_IO0 -
P2 PH3 QSPI_BK2_IO1 -
P3 PH4 ULPI_NXT -
P4 PH5 SDR_SDNWE -
T11 PH6 SDR_SDNE1 -
U13 PH7 SDR_SDCKE1 -
T13 PH8 FMC_D16 -
R13 PH9 FMC_D17 -
P13 PH10 FMC_D18 -
P14 PH11 FMC_D19 -
R14 PH12 FMC_D20 -
D16 PH13 FMC_D21 -
B17 PH14 FMC_D22 -
B16 PH15 FMC_D23 -
A16 PI0 FMC_D24 -
A15 PI1 FMC_D25 -
B15 PI2 FMC_D26 -
C14 PI3 FMC_D27 -
A4 PI4 FMC_NBL2 -
Table 33. STM32H743I-EVAL I/O assignment (continued)
Pin No. Pin Name Default function Alternative function
