8 STM32H745I-DISCO and STM32H750B-DK I/O assignment

Table 15. STM32H745I-DISCO and STM32H750B-DK I/O assignment

Pin Name Pin Number Signal or Label Comment

PA0 N5 STMOD#1-CTS -

PA1 N4 MII_RX_CLK -

PA2 N3 MII_MDIO -

PA3 U2 STMOD#14-PWM -

PA4 U3 STMOD#13-ADC -

PA5 T3 OTG_FS2_PSO -

PA6 R3 ARD_D3 -

PA7 R5 MII_RX_DV -

PA8 E5 ARD_D5 -

PA9 D15 VBUS_FS2 -

PA10 D14 USB_OTG_FS2_ID -

PA11 E17 USB_OTG_FS2_N -

PA12 E16 USB_OTG_FS2_P -

PA13 C15 SWDIO SWDIO

PA14 B14 SWCLK SWCLK

PA15 A14 STMOD#1_SPI_CS||T_JTDI -

PB0 U5 MII_RXD2 -

PB1 T5 MII_RXD3 -

PB2 R6 MII_TX_ER -

PB3 C6 SWO -

PB4 B7 ARD_D10 -

PB5 A5 FDCAN2_RX -

PB6 B5 ARD_D1 -

PB7 C5 ARD_D0 -

PB8 D5 SDIO1_D4 -

PB9 D4 SDIO1_D5 -

PB10 P11 VCP_TX -

PB11 P12 VCP_RX -

PB12 T14 LCD_RST -

PB13 U14 FDCAN2_TX -

PB14 U15 STMOD#9-MISOs -

PB15 T15 ARD_D11 -

PC0 L2 ARD_A0 -

PC1 M2 MII_MDC -

PC2 M3 MII_TXD2 -

PC3 M4 MII_TX_CLK -

PC4 T4 MII_RXD0 -

UM2488

STM32H745I-DISCO and STM32H750B-DK I/O assignment

UM2488 - Rev 4

page 22/55
