7.12 CN15 USB power connector
Figure 12. CN15 USB Micro-B connector (front view)
Table 14. CN15 USB Micro-B connector
Pin number Description Pin number Description
1 VBUS 4 NC
2 NC 5 GND
3 NC - -
UM2488
CN15 USB power connector
UM2488 - Rev 4
page 21/55
