ST STM32H745I-DISCO

Pin Name Pin Number Signal or Label Comment
PJ13 E10 LCD_B1 -
PJ14 D10 LCD_B2 -
PJ15 B10 LCD_B3 -
PK0 J14 LCD_BL -
PK1 J15 ARD_D4 -
PK2 H17 LCD_G7 -
PK3 C8 LCD_B4 -
PK4 B8 LCD_B5 -
PK5 A8 LCD_B6 -
PK6 C7 LCD_B7 -
PK7 D7 LCD_DE -
- L16 DSI_CK_P NC
- L17 DSI_CK_N NC
- M16 DSI_D0_P NC
- M17 DSI_D0_N NC
- K16 DSI_D1_P NC
- K17 DSI_D1_N NC
- T1 ARD_A2 -
- T2 ARD_A3 -
- R1 ARD_A4 -
- R2 ARD_A5 -
- E9 VDD ARD_D7
- E11 VDD -
- F5 VDD -
- G5 VDD -
- G13 VDD -
- H5 VDD EXT_RST
- H13 VDD -
- J13 VDD -
- K13 VDD -
- L13 VDD -
- M13 VDD ARD_A0
- N12 VDD -
- N11 VDD -
- N10 VDD -
- N7 VDD DSIHOST_TE
- L5 VDD -
- K5 VDD -
- E6 VDD -
P11 F1 VDDIO_SD1 -
UM2488
STM32H745I-DISCO and STM32H750B-DK I/O assignment
UM2488 - Rev 4
page 26/55
