UM1018 Connectors
Doc ID 18141 Rev 1 21/44
25 PD3 USART2_CTS JP9 open
27 PD5 USART2_TX / LED4 JP19 open
29 PD7 CS_uSD Remove SD card from CN4
31 VLCD - -
33 PB3 JTDO / COMP_POT- JP17 open
35 PB5 TEMP_SMBAI / COMP_POT+ JP17 and JP11 open
37 PB7 I2C_TEMP_SDA Remove R62
39 GND - -
41 PE2 LCD glass_SEG38 / TRACE_CLK Remove LCD glass U20
43 PE4 TRACE_D1 -
45 PB8 LCD glass_SEG16 Remove LCD glass U20
47 PE6 TRACE_D3 / SD Card detection JP2 open
49 D5V - -
2 PC6 TS_KEY1 Remove R14
4 PC8 TS_SHIELD -
6 PA8 LCD glass_COM0 Remove LCD glass U20
8 PA10 LCD glass_COM2 Remove LCD glass U20
10 GND - -
12 PA11 USB DM Remove R16
14 PA13 JTMS -
16 PA14 JTCK -
18 PC11 LCD glass_SEG41 / USART3_RX JP8 open
20 PA15 JTDI -
22 PD0 LED1 Remove R111
24 PD2 LCD glass_SEG43 Remove LCD glass U20
26 PD4 USART2_RTS/ LED3 JP18 open
28 PD6 USART2_RX Remove R19
30 GND - -
32 PH2 CS_LCD -
34 PB4 JTRST / LDR JP10 open
36 PB6 I2C_TEMP_SCL Remove R69
38 PE0 LCD glass_SEG36 Remove LCD glass U20
40 PE1 LCD glass_SEG37 Remove LCD glass U20
42 PE3 LCD glass_SEG39 / TRACE_D0 Remove LCD glass U20
Table 15. Daughterboard extension connector CN6 (continued)
Pin Description Alternative function
How to disconnect with function block on
STM32L152-EVAL board
