Pin Pin name Signal name
15 SCL DSCL
16 SDA DSDA
17 GND GND
18 +5V 5V_VIN
19 DET HPD
7.13
Wi‑Fi
®
and Bluetooth
®
Low Energy
7.13.1 Description
The STM32MP157C-DK2 Discovery kit support Wi‑Fi
®
802.11b/g/n and Bluetooth
®
Low Energy (BLE) V4.1.
These functions are supported with the LBEE5KL1DX-883 MURATA module. This module is driven by a SDIO for
the Wi‑Fi
®
interface, and a USART for the Bluetooth
®
. The PCM format is used for audio data.
7.13.2 Operating voltage
The LBEE5KL1DX-883 module supports the 3.3 V voltage range.
7.13.3
Wi‑Fi
®
I/O interface
Table 17 describes the I/O configuration for the Wi‑Fi
®
interface.
Table 17. I/O configuration for the Wi‑Fi
®
interface
I/O Configuration
PB4 PB4 is connected to SDMMC2_D3
PB3 PB3 is connected to SDMMC2_D2
PB15 PB15 is connected to SDMMC2_D1
PB14 PB14 is connected to SDMMC2_D0
PG6 PG6 is connected to SDMMC2_CMD
PE3 PE3 is connected to SDMMC2_CK
PH4 PH4 is connected to WL_REG_ON
PD0 PD0 is connected to WL_HOST_WAKE
7.13.4
Bluetooth
®
Low Energy I/O interface
Table 18 describes the I/O configuration for the Bluetooth
®
Low Energy interface.
Table 18. I/O configuration for the Bluetooth
®
Low Energy interface
I/O Configuration
PD5 PD5 is connected to USART2_TX
PD6 PD6 is connected to USART2_RX
PD4 PD4 is connected to USART2_RTS
PD3 PD3 is connected to USART2_CTS
