ST STM32MP157C-DK2 User Manual

1 Features
• Common features
– STM32MP157 Arm
®
-based dual Cortex
®
-A7 32 bits + Cortex
®
-M4 32 bits MPU in TFBGA361 package
– ST PMIC STPMIC1
– 4-Gbit DDR3L, 16 bits, 533 MHz
– 1-Gbps Ethernet (RGMII) compliant with IEEE-802.3ab
– USB OTG HS
– Audio codec
– 4 user LEDs
– 2 user and reset push-buttons, 1 wake-up button
–
5 V / 3 A USB Type-C
™
power supply input (not provided)
– Board connectors:
◦ Ethernet RJ45
◦ 4 × USB Host Type-A
◦
USB Type-C
™
DRP
◦
MIPI DSI
SM
◦ HDMI
®
◦ Stereo headset jack including analog microphone input
◦ microSD
™
card
◦ GPIO expansion connector (Raspberry Pi
®
shields capability)
◦ Arduino
™
Uno V3 expansion connectors
– On-board ST-LINK/V2-1 debugger/programmer with USB re-enumeration capability: Virtual COM port
and debug port
– STM32CubeMP1 and full mainline open-source Linux
®
STM32 MPU OpenSTLinux Distribution (such
as STM32MP1Starter) software and examples
– Support of a wide choice of Integrated Development Environments (IDEs) including IAR
™
, Keil
®
, GCC-
based IDEs
• Board-specific features
– 4" TFT 480×800 pixels with LED backlight, MIPI DSI
SM
interface, and capacitive touch panel
– Wi‑Fi
®
802.11b/g/n
– Bluetooth
®
Low Energy 4.1
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
UM2534
Features
UM2534 - Rev 1
page 2/47
