Hardware and layout UM1574
16/48 Doc ID 023645 Rev 1
Figure 8. STM8AF board bottom layout
MS31063V1
SB1 (RESERVED)
SB2 (STM_RST)
SB3 (MCO)
SB4, SB5
(RESERVED)
SB6 (L99PM62GXP)
SB7 (CAN supply)
SB8 (Start-up delay)
SB9 (CAN
terminating resistor)
SB10, SB11 (USB5V)
SB12, SB13 (RESERVED)
