ST STM8A-DISCOVERY - Figure 13. STM8 AL Board Bottom Layout

UM1574 Hardware and layout
Doc ID 023645 Rev 1 25/48
Figure 13. STM8AL board bottom layout
SB1 (RESERVED)
SB2 (STM_RST)
SB3 (MCO)
SB9, SB10
(Xtal 32.768 kHZ)
SB13, SB14 (USB5V)
SB 12 (RESERVED)
SB6, SB7, SB8
(I
DD
circuitry)
SB15, SB16
(RESERVED)
MS31064V1
SB11
(L99M62GXP Reset)
SB4, SB5 (RESERVED)
