Evaluation kit board settings UM0671
14/23 Doc ID 15330 Rev 4
Table 8. STM8/128-EVAL board settings
Jumper Description Configuration
JP1
Set to “STice” to keep motherboard MCU Reset pin low to enable
correct TS daughterboard MCU functionality. (Default configuration)
JP3
Connect both PSU and DTB jumpers to supply power supply the TS
daughterboard. (Default configuration)
123
12
12
DTB PS
U
