ST STM8S User Manual

UM0671 Evaluation kit board settings
Doc ID 15330 Rev 4 7/23
3 Evaluation kit board settings
3.1 STM8S touch sensing daughterboard
Figure 4. STM8S TS daughterboard overview
STM8S MCU
This board uses a STM8S microcontroller (STM8S207K6T6C) in a 32-pin LQFP package.
Keys
The 5 touchkeys (electrodes) are made of a simple copper surface.
4 direction keys
1 selection key
Slider
Connectors to
board
Analysis
I2C connector
SWIM
STM8S MCU
connectors
connector
STM8/128-EVAL
and jumper
I
DD
measurement
