STA-RITE MAX-E-PRO - Page 8

8
TABLE II - RECOMMENDED FUSING AND WIRING DATA – P6RA MODELS
Serv. to Motor - Dist. in Ft. (M)
Motor Branch Fuse Max Load Voltage/ 0-100' 101-200' 201-300'
HP Rating Amps* Amps Hz/Phase (0-30 M) (30-60 M) (60-90 M)
P6RA Models:
1 20/15 15.3/7.6 115/230/60/1 12/14(3/2) 8/14(8.4/2) 6/14(14/2)
1-1/2 30 19.2 115/60/1 10(5.5) 8(8.4) 6(14)
1-1/2 15 9.6 230/60/1 14(2) 14(2) 12(3)
215 12.0 230/60/1 14(2) 14(2) 12(3)
P6RA 2-Speed Models:
1-1/2 15 9.2/2.5 230/60/1 14(2) 14(2) 12(3)
21510.1/3.7 230/60/1 14(2) 14(2) 12(3)
* Time delay fuses are recommended instead of standard fuses in any motor circuit.
Wire
Size
AWG
(mm
2
)
}
TABLE I - RECOMMENDED FUSING AND WIRING DATA – P6E MODELS
Serv. to Motor - Dist. in Ft. (M)
Motor Branch Fuse Max Load Voltage/ 0-100' 101-200' 201-300'
HP Rating Amps* Amps Hz/Phase (0-30 M) (30-60 M) (60-90 M)
P6E Models:
1/2 15 11.0 115/60/1 14(2) 10(5.5) 8(8.4)
3/4 20 13.8 115/60/1 12(3) 10(5.5) 8(8.4)
125 16.0 115/60/1 12(3) 8(8.4) 6(14)
1/2 15 5.5 230/60/1 14(2) 14(2) 14(2)
3/4 15 6.9 230/60/1 14(2) 14(2) 14(2)
115 8.0 230/60/1 14(2) 14(2) 14(2)
1-1/2 15 10.4 230/60/1 14(2) 12(3) 12(3)
215 11.2 230/60/1 14(2) 12(3) 12(3)
325 15.8 230/60/1 12(3) 12(3) 10(5.5)
* Time delay fuses are recommended instead of standard fuses in any motor circuit.
Wire
Size
AWG
(mm
2
)
}
