Stabila LD 520 - Operations; Switching ON;OFF; Message Codes; Permanent; Minimum-Maximum measuring

LD 520
5
ENOperations
Switching ON/OFF Clear Message Codes
ON
OFF
2 sec
Device is turned
OFF.
i
If no key is
pressed for 180
sec, the device
switches off au-
tomatically.
1x
Undo last action.
2x
Leave actual func-
tion, go to default
operation mode.
If the info icon appears with a
number, observe the instructions in
section "Message Codes".
Example:
Multifunctional endpiece
i
The orientation
of the endpiece
is automatically
detected and
the zero point is
accordingly ad-
justed.
Permament / Minimum-Maximum measuring
1
2 sec
8.532 m
Used to measure room diagonals (maximum val-
ues) or horizontal distance (minimum values)
The minimum and maximum dis-
tance measured is displayed (min,
max.). The last value measured is
displayed in the main line.
min.
max.
2
Stops permanent / minimum-
maximum measuring.
3
