3. Components of the unit
Electronic module
(dust-proof and waterproof in accordance with IP 65)
Battery compartment lid
2 Displays
Vials - vertical and horizontal
Removable, shock-absorbing end caps
Anti-slip stopper
Rare-earth magnet ( 196 M )
Buttons:
On/Off
Units of measurement: °, %, mm/m, in/ft
Calibration and sensor adjustment
HOLD – locking measurements
Reference – freely selectable zero position
Acoustic guidance
Key lock
Display lighting
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
2
3
1
8
4
4
12
