Stairmaster STEPMILL 7000 PT - Console and Speed Control Diagnostics

•
•
•
CONSOLE DIAGNOSTIC TESTS
The following tests must be performed while the console is in the DIAGNOSTIC mode .
To activate the DIAGNOSTIC mode, press [t ARROW] , [1], [0], [7], [ENTER]. The numbers
will not appear on the display area as you enter them . If the console fails any test, the
console should be replaced or exchanged. To return to the ATTRACT mode, press either
[CLEAR] or [RESET] while in the DIAGNOSTIC mode .
Display Test
Use t his test if the console display or text bar exhibits blank spots during use. This test
checks for inoperable Light Emitting Diodes (LEOs) in the console display and the text
bar . If any LED will not light , replace the console.
1. Press [0] to start the test.
2. All LEOs in the console display will flash on and off as a block. The 26 letters
(A-Z) will scroll across the text bar.
3. Press [CLEAR] to end the test.
Speaker Test
Use this test to make sure the console speaker is fully operational. The speaker will
ascend and then descend through the musical scale .
1.
Press [1] to start the test.
2. Press [ENTER] to pause the test. Press [CLEAR] to end the test.
Keypad Test
Perform this test if you are having trouble entering data into the console. If you cannot
enter the DIAGNOSTIC mode due to an inoperable keypad, replace the console .
1.
Press [2] to start the test.
2. The display LEOs will light up in an L-shaped formation, representing the
keypad matrix . Pressing a button on either the exercise program keypad or the
function keypad will light an LED within the outline on the display that
corresponds to that button 's position on the console.
3. Firmly press each button . If the LED corresponding to the button you pushed
does not light up, the keypad is bad and the console should be replaced.
Page 31
