Stanley D 210/8/24S User Manual

G
B
15
Before using the compressor, read the instructions for use carefully
and comply with the following safety precautions. Consult this
handbook if you have any doubts regarding functioning.
Preserve all the documentation so that anyone who uses the
compressor can consult this beforehand.
SAFETY PRECAUTIONS
1
An ACOUSTIC PRESSURE value of 4 m. corresponds to the ACOUSTIC
POWER value stated on the label located on the compressor, minus
20 dB.
BEFORE USE
• The compressor must be used in a suitable environment (well
ventilated with an ambient temperature of between +5°C and +40°C)
and never in places affected by dust, acids, vapors, explosive or
flammable gases.
•Always maintain a safety distance of at least 4 meters between the
compressorandtheworkarea.
•Any coloring of the belt guards of the compressor during painting
operationsindicatesthatthedistanceistooshort.
•Insert the plug of the electric cable in a socket of suitable shape, voltage
andfrequencycomplyingwithcurrentregulations.
•Useextensioncableswithamaximumlengthof5metersandofsuitable
cross-section.
•Theuseofextensioncablesofdifferentlengthandalsoofadaptersand
multiplesocketsshouldbeavoided.
•Always use the switch of the pressure switch to switch off the compressor
•Alwaysusethehandletomovethecompressor.
•When operating, the compressor must be placed on a stable, horizontal
surfacetoguaranteecorrectlubrication.
GENERAL SAFETY INSTRUCTIONS
•Neverdirectthejetofairtowardspersons,animalsoryourbody.(Always
wear safety goggles to protect your eyes against flying objects that may be
liftedbythejetofair).
•Never direct the jet of liquids sprayed by tools connected to the compressor
towardsthecompressor.
•Neverusetheappliancewithbarefeetorwethandsorfeet.
•Never pull the power cable to disconnect the plug from the socket or to
movethecompressor.
•Neverleavetheapplianceexposedtoadverseweatherconditions.
•Nevertransportthecompressorwiththereceiverunderpressure.
•Donotweldormachinethereceiver.Inthecaseoffaultsorrusting,replace
theentirereceiver.
•Neverallowinexpertpersonstousethe compressor.Keepchildrenand
animalsatadistancefromtheworkarea.
•Thisapplianceisnotintendedforusebypersons(includingchildren)with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their
safety.
•Children should be supervised to ensure that they do not play with the
appliance.
•Donotpositionflammableornylon/fabricobjectsclosedtoand/oronthe
compressor.
•Nevercleanthecompressorwithflammableliquidsorsolvents.Checkthat
youhaveunpluggedthecompressorandcleanwithadampclothonly.
•Thecompressormustbeusedonlyforaircompression.Donotusethe
compressorforanyothertypeofgas.
•The compressed air produced by the compressor cannot not be used
for pharmaceutical, food or medical purposes except after particular
treatmentsandcannotbeusedtofilltheairbottlesofscubadivers.
OPERATION
•To avoid overheating of the electric motor, this compressor is
designed for intermittent operation as indicated on the technical
dataplate (for example, S3-25 means 2.5 minutes ON, 7.5 minutes
OFF). In the case of overheating, the thermal cutout of the motor
trips, automatically cutting off the power when the temperature is
too high. The motor restarts automatically when normal temperature
conditions are restored.
•To facilitate restart of the compressor, in addition to the operations
indicated, it is important to return the button of the pressure switch to the
OFFpositionandthentoONagain(figures 1-2).
•Single-phase versions are fittedwitha pressure switch equipped witha
delayedclosingairdischargevalvewhichfacilitatesstart-upofthemotor.
Therefore venting of air from this valve for a few seconds with the receiver
emptyisnormal.
•All the compressors are fitted with a safety valve that is tripped in the case
ofmalfunctioningofthepressureswitchinordertoassuremachinesafety.
•The red notch on the pressure gauge refers to the maximum operating
pressureofthetank.Itdoesnotrefertotheadjustedpressure.
•Whenfittingatool,theflowofairinoutputmustbeswitchedoff.
•When using compressed air, you must know and comply with the safety
precautionstobeadoptedforeachtypeofapplication(inflation,pneumatic
tools,painting,washingwithwater-baseddetergentsonly,etc.).
ASSEMBLY
2
You must fully assemble the appliance before using it for the first time.
Fitting the wheels
Fit the supplied wheel kit as shown in fig. 3.Assemblybysequence:a,b,
c,d,e.
Fitting the rubber foot
Fit the supplied rubber stopper as shown in fig. 4.
Fitting the air filter
Remove the shipping plug with a screwdriver or similar and screw the air
filtersecurelytotheequipment(fig. 5).
Fitting the transport handle
Screw the transport handle to the compressor as shown in fig. 15.
VOLTAGE
3
Thecompressorisequippedwithamainscablewithshock-proofplug.This
canbeconnectedtoany230V~50Hzshock-proofsocketwhichisprotected
bya16Afuse.Beforeyouusethemachine,makesurethatthemainsvolt-
agecomplieswiththespecificationsontheratingplate.Longsupplycables,
extensions,cablereelsetc.causeadropinvoltageandcanimpedemotor
start-up.Inthecaseoflowtemperaturesbelow+5°C,motorstart-upisjeop-
ardizedasaresultofstiffness.
Connection of the mains plug (electrical information for the BS plug)
Important!
The wires in the mains lead fitted to this product are coloured in accordance
with the code shown in fig. 16.
● The 3 pin plug must comply to BS1363/A.
● Fuse must comply to BS1362.
If for any reason the 13 amp plug fitted to this product requires replacement
it must be wired in accordance with the following instruction:
Do not connect the brown (live) or blue (neutral) to the earth pin marked
‘E’
on the 3 pin plug.
Connect the Blue wire to the terminal marked Neutral (N). Connect the
BrownwiretotheterminalmarkedLive(L).ConnecttheYellow&Greenwire
totheterminalmarkedEarth(E).Ensurethattheouterinsulationisgripped
by the cord grip and that the wires are not trapped when replacing the plug
cover.Themainsleadonthis productisfittedwitha13 amp (BS1363/A)
plug.A13amp(BS1362)fusemustbefittedintheplug.
If in doubt consult a qualified electrician
Therearenouserserviceablepartsinsidethisproductexceptthosereferred
tointhemanual.Alwaysreferservicingtoqualifiedservicepersonnel.Never
removeanypartofthecasingunlessqualifiedtodoso;thisunitcontains
dangerousvoltages.
Warning!
For your protection if this product is to be used outdoors it should not be
exposedtorainorusedindamplocations.Donotplacetheproductondamp
surfaces,useaworkbenchifavailable.Foraddedprotectionuseasuitable
Preserve this handbook for future reference
