MB05 User Manual ◄ 29
ITEM P/N QTY DESCRIPTION
3 09728 2 PIN RETAINER SPRING
4 09764 2 PIN RETAINER
5 16549 1 DOWEL PIN
6 19095 1 O-RING •
7 22980 2 RETAINER SPRING
8 22993 4 TIE ROD WASHER
9 22998 2 O-RING •
10 24112 3 O-RING •
11 24117 2 O-RING •
12 25008 1 ROD WIPER •
16 32165 1 CHARGE VALVE ASSY
18 69839 1 PISTON
19 69840 1 PISTON SLEEVE
20 69841 1 SEAL CARRIER
21 69843 3 ROD SEAL •
22 69844 1 O-RING •
23 69846 1 VALVE SPOOL
24 69847 1 VALVE SLEEVE
25 69849 1 VALVE CAP
26 69850 1 UPPER ACCUMULATOR
27 69852 1 MAIN BODY ASSY (INCL ITEMS
12, 21, 24, 38 & 40)
30 69855 1 LOWER BODY ASSY (INCL ITEMS
3, 4, 7, 31-34, 39, 41)
31 69858 1 BUSHING - TOOL STOP
32 69859 1 BUSHING - LOWER TOOL
33 69860 2 DOWEL PIN
34 69861 4 ROLL PIN
35 69862 1 RETAINER PIN - TOOL
36 69869 1 POWER CELL
37 69879 4 TIE ROD
38 71094 1 VALVE STRIKE PLATE
39 350223 2 HOLLOW HEX PLUG
40 350237 2 HOLLOW HEX PLUG
41 372003 1 GREASE FITTING
SEAL KIT
70984
• DESIGNATES
PARTS INCLUDED IN
SEAL KIT
MB05 POWER CELL PARTS LIST
