4. Attaching the Accessories
e following accessories are necessary when mounting the printer to a wall.
• Upper guide and two anged screws
• Holder plate and two angeless screws
e following accessories are necessary when positioning the printer vertically.
• Upper guide and two anged screws
• Four rubber feet
4-1. Attaching the Upper Guide
1) Push the cover open lever, and open the printer cover.
2) Fit the upper guide onto the sha until the hooks on the guide click into place.
3) Tighten the two screws (M3x6 anged screws) that were supplied to secure the upper guide
in place.
Hooks
Shaft
Upper guide
Flanged screws
