– 104 –
APPENDIX
A-1. General Specifications
(1) Printing method Direct line thermal printing
(2) Print speed Max. 1200 dots/sec. (150 mm/sec.)
(3) Dot density 203 dpi: 8 dots/mm (0.125 mm/dot)
(4) Printing width Max. 104 mm
(5) Number of print columns
69 (12 × 24 dots)
(6) Roll paper Refer to chapter 2 for details on the recommended roll
paper.
Paper width: 111.5 ± 0.5 mm
Roll diameter: ø100 mm or less
(7) Overall dimension Standard model: 180 (W) × 213 (D) × 148 (H) mm
Wall mount model: 180 (W) × 153 (D) × 213 (H) mm
(8) Weight Standard model: Approx. 1.9 kg
Wall mount model: Approx. 2.2 kg
(9) Noise Approx. 55 dB
Standard Model
Appendix A: Specifications
180 mm
148 mm
213 mm
