Item Description
Keypad Test
This is a test used to verify that all the keys are responding on the display. When toggled,
every subsequent key press will display the name of the key on the display.
Heart Rate Test This is a test used to verify that the contact and/or telemetry heart rate is working.
Serial Port Test Manufacture test only.
Error Stats Error Stats has a sub menu containing all the error codes and a counter for how many
times each error code has occurred.
The errors are:
• Key Down
• Check Motor System
• Check Speed System
• No Rail Stop
• Speed Change
• Elevation Stall
• Elevation Range
• Elevation Lost
• Fuse Bits Error
Last Error List
The Last Error List has a sub menu that displays the last 5 errors that have occurred on
the treadmill as well as other details about how the treadmill was performing at the time
of the error.
Calibration Values
Calibration Values has a sub menu of settings that are related specically to elevation or
speed calibration.
10 Rev
This the distance (in inches) that the running belt moves for ever
ten rotations of the ywheel. This number is critical for accurate
speed calculations.
CNT/RV
This is the number of counts (of the RPM sensor) that equal one
revolution of the ywheel (which is 31). This number must never
change.
Minimum PWM
This is the PWM number at the minimum speed. This number is
set automatically during motor calibration.
½ Maximum
This is the PWM number at half the max speed. This number is set
automatically during motor calibration.
Maximum PWM
This the PWM number at the maximum speed. This number is set
automatically during motor calibration.
Person Detect 1 This setting has no function.
Person Detect 2 This setting has no function.
Person Detect 3 This setting has no function.
Elevation Zero
This is the incline value of the elevation motor at 0% elevation. It
can be manually adjusted.
Elevation Max
This is the incline value of the elevation motor at max elevation. It
can be manually adjusted.
