32
Installation
Plug in the 90˚ end of the gimbal cable to the
control box, wrap a loop or two around the post
and plug in the Volt.
The LEMO connectors rotate 90˚ in the control
box to allow for convenient cable placement.
TIP: Depending on your normal builds, you may
prefer the optional “long” gimbal cable.
NOTE: For preassembled Volt gimbals, you
do NOT need to press the ip button. This
procedure was done at the factory.
Your Volt equipped sled should be ready for
action! Now go back to page 9, and get ready
to balance before powering on.
