Steadicam Volt - Steadicam Volt Components Overview

2
Trunnion pulley
Handle pulley
Trunnion motor
and belt
Pan encoder
Pan encoder ring inside
Steadicam
®
Volt
™
shown on M-2
™
gimbal
Main power/control input
& encoder jack
Handle motor
and belt
Mode LED (green)
Gimbal button
Power LED (blue)
Trunnion screw access
Invert button access
Components
Gimbal clamp lever
1.5” post
1.75” post
1.58” post
M-2
™
gimbal post spacers Thumb button
