Steinberg UR242 - dspMixFx UR242 Mixer and Effects

Panel Controls and Terminals
UR242 Operation Manual 8
dspMixFx UR242
This software is for operating the convenient built-in DSP
mixer and DSP effects. The DSP mixer allows you to mix
up to four input channels down to one stereo output. A
number of DSP effects for processing the input signals are
also provided, and since the processing/mixing is
hardware-based, there is no monitoring latency.
NOTE
You cannot operate dspMixFx UR242 while a Cubase series
DAW is running. When Cubase is running, configure the DSP
mixer and DSP effect from “Dedicated Windows for Cubase
Series” (page 13).
How to Open the Window
Windows
[All Programs] or [All apps]  [Steinberg UR242] 
[dspMixFx UR242]
Mac
[Applications]  [dspMixFx UR242]
Controls and Functions
Tool Area
This is the area for configuring the overall common settings
of dspMixFx UR242.
1 Quit
Quits dspMixFx UR242.
2 Minimize
Minimizes the dspMixFx UR242 window.
3 Menu
Provides four different menus for various settings.
4 Scene
Indicates the scene name. You can change the scene
name by clicking on it. Clicking the button on the right
opens the window for calling up other scenes. Call up the
desired scene by clicking it. To cancel calling up the scene,
click outside of the window.
5 STORE
Opens the Scene Store window. Enter the desired scene
name into the STORE NAME field. Select the destination
for storing the scene in the No. NAME field. Click [OK] to
store the scene.
6 Selecting windows
Selects the desired dspMixFx UR242 window. The selected
window icon lights in red.
7 Help
Opens the Operation Manual (this manual).
Main Window
This window is for configuring the entire signal flow.
Menu Description
Open Opens the settings file of dspMixFx
UR242.
Save Saves the settings file of dspMixFx
UR242 to a computer.
Import Scene Imports a scene from the settings file of
dspMixFx UR242. Select the desired
settings file of dspMixFx UR242 and
import the desired scene on the left side
of the [IMPORT SCENE] window. The
window appears after the file is selected
in the file selection dialog. Select the
destination for importing on the right side
of the window. Click [OK] to import it.
Initialize All Scenes Deletes all the saved scenes.
12 34 567
Menu Description
Main window (page 8)
Setup window (page 11)
Information window (page 12)
Channel Area (page 9) MIX Area (page 11)
DAW Area (page 10)
Master Area (page 10)
Headphone Area (page 11)
