PRESTART CHECKS 650/800/850 GUEPARD
41
Air pressure measurement
Check the air pressure using a low pressure gauge.
_______________________________
The pressure should be measured twice, and the
second value should be counted. The valve or
pressure gauge contamination may impair the
first measurement.
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
1. Low pressure gauge.
It is recommended to adjust the pressure with a cold
tyre. Bring the tyre pressure to the following standard
values:
Standard Minimum Maximum
35.0 kPa 33.0 kPa 69.0 kPa
Front (0.35 kg/cm²) (0.33 kg/cm²) (0.69 kg/cm²)
5.0 psi 4,7 psi 9,9 psi
35.0 kPa 33.0 kPa 69.0 kPa
Rear (0,35 kg/cm²) (0,33 kg/cm²) (0,69 kg/cm²)
5.0 psi 4.7 psi 9.9 psi
Tyre wear control
It is recommended to change the tyres if the tread
pattern depth reduces to 5 mm or less.
а. Tyre tread pattern depth
Chassis fixture components
Make sure that all the nuts, bolts and screws are
tightened as required.
Lighting devices, switches
Make sure that all the lighting devices and additional
equipment are operating. If necessary, correct the
fault.
