FLIGHT MANUAL TSA-M, VARIANT S6
Doc.-No.: P400-006.000 E Page: 7-11 Revision: 1
Date of Issue: 07. October 2008 Date of Rev.: 28.01.2011
(1)
Canopy-Locks White handles on left and right side of canopy-frame
(additional rear-canopy-hook at upper rear middle of
canopy-end)
(2)
Air-Brake-Lever Blue lever on left cockpit-wall and on left side of
center-console
(3)
Cabin-Ventilation Black pull-button, one at each seat to control cabin-
ventilation
(4)
Control-Stick Dual-controls, centered forward of each seat
(5)
Wheel-Brake-
Lever
Black lever at control-stick, when parking lock lever
with pin
(6)
Choke-Lever Black lever on forward center-console on the left side.
The adjustment of the Choke-Lever is realised by pre-
defined clamping.
(7)
Canopy-Jettison Red handle on top of the forward center-console,
below the instrument-panel
(8)
Cowl-Flaps-Lever Black handle on top of the forward center-console
below Canopy-Jettison handle (to operate the inlets
and outlets of the engine-cowling). The lever is
unlocked by pushing a push-button and locked again
by releasing the button.
(9)
Rudder-Pedals One pair for each seat in the foot-area.
(10)
Flap-Lever Black lever on the right side of the center-console. To
unlock push to the right.
(11)
Throttle Black lever, centered on the center-console.
(12)
Rudder-Pedal-
Handle
One for each seat, in front of the control-stick. Pull to
unlock
(13)
Seat-Back-
Adjustment
For each seat, located at the left and right on the
bottom end of the backrest.
Release to adjust the backrest at its lower attachment
by pulling the slider to the inside
