Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
100
Chapter 6 introduction to the supporting products
In the following Table 6.1, AS 380 series elevator integrated drive controller‘s supporting
materials are tabulated for users making choices in accordance with the specific configuration of
their elevators:
Name Description Remarks
Car top Control Board SM-02/H
Collect and process car top information and other
related information
required part,
Car top Extension Board
SM.09IO/B
Control rear door open/close signal and collect
information related to rear door
required part for
rear door
Car Control Board SM.02/G
Collect and process car information and other related
information
required part
Car extension board SM.09IO/B
Collect and process door open holding button, NS-SW
switch information
optional part
Instruction control panel SM-03
Command panel, installed in car operation panel,
collect information related car call and etc
Required part
Call &
display
control
SM-04
SM-04-VRF optional part1
For call and display required part
SM-04-VSC optional part2
SM-04-HRC optional part3
SM-04-HSC optional part4
SM-04-VHL optional part5
SM-04-UL optional part6
SM-04-VL/A3 optional part7
SM-04-VL/B3 optional part8
SM-04-VSD Optional part 9
SM-04-VRJ Optional part 10
Calling board For installation of call/ display panel optional part
Operation box
For installation of instruction panel and car display
board
optional part
Brake resistor
Installed in the control cabinet, for the heat dissipation
of elevator tractor. The controller of various frequency
should be equipped with the corresponding brake
resistors
optional part
ABZ incremental 12V PG card
AS.T025
For asynchronous motor or synchronous motor with
incremental encoder
Required par as per
the encoder type
SIN/COS PG card AS.T024 For synchronous motor
ABZ incremental 5V PG card
AS.T041
For asynchronous motor or synchronous motor with
incremental encoder
Endat PG card AS.L06/L For synchronous motor
Elevator control cabinet
For elevator control, including AS380 control cabinet
and the all accessories in the cabinet
Optional
