Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
11
Chapter one: General knowledge of the integrated drive controller
This chapter introduces the general information of AS380 series integrated drive controller,
including the voltage grade and adaptive motor capacity of the integrated device, and items
checkup in the cases. Besides, the chapter describes in detail the notice items during the process of
integrated device installation, wiring, operation, maintenance and disposal. Please read carefully
this chapter for the safe operation of the integrated device and prolonging of the service life.
1.1 scope of application
The voltage grade of AS380 series elevator integrated drive controller is 200V, 400V. AS380
series elevator integrated drive controller is both asynchronous motor and synchronous motor
compatible. The mating motor capacity is 1.1kW～75kW right now. the max floor single elevator
support is 64 floor. The max quantity of elevator group control is up to 8 units. For the
configuration beyond the above scope, please contact the engineer center of our company.
1.2 items in the cases
◎ Do not install frequency converter damaged or components incomplete。
Otherwise high risk of fire, personal injury。
Please confirm the following item after opening the cases
Any damage caused by transportation, the conformity of items and parameter on the machine
nameplate to those in the purchase requirements,
Please contact the manufacturer or supplier for the solution once any inconformity or items
omission.
1.3 model description
AS380 series elevator integrated drive controller model number illustration fig 1.1
NO
Mating motor
07P5
7.5kW
Series name
2
200V
4
400V
0011
0015
18P5
0022
11kW
15kW
18.5kW
22kW
T
3-phase
S
1-phase
01P5
03P7
05P5
1.1kW
3.7kW
5.5kW
2.2kW
02P2
AS380 4 T 0022
0030
30kW
0037
0045
0055
0075
37kW
45kW
55kW
75kW
