Table 4.1 requirement for inductor and magnetic vane
Category Leveling Inductor
Door Range Inductor
for PRE-OPENING of
door
Magnetic Vane
Type, Material Either Permanent magnet
inductor or photoelectric
switch works. The latter type
is recommended for higher
response precision
Permanent-magnet
inductor
Iron plate thickness
≥1.5mm
Qty. 2 2 as per the number of floors if no
other special required.
Height,
Length, Depth
The clearance between top
and bottom surface of upper
and lower inductor is about
200.
Two door range inductors
must be arranged at a
same level and able to
act at the same time.
Magnetic vane is 220 long, users
are recommended not to make it
less than this value. The inserted
depth of photoelectric and
magnetic switch is more than 2/3.
Installation
Location
Car top Car top Elevator shaft
Precautions Grounded Grounded
Table 4.1 Detailed Requirements of Inductor and Magnetic Vane
Important! When inductors are made of non-insulated materials, they must be grounded
appropriately!
4.4 main circuit terminal wiring
4.4.1 The arrangement of main circuit terminal
4.4.2 The main circuit terminal labeling and function description
Please take reference to table 4.1 for main circuit terminal function description
Table 4.1 main circuit terminal function description
Terminal mark Terminal function description
○＋1
DC reactor can be connected. Shorting before delivery
○＋2
○＋2
external brake resistor connected
B
○－ DC bus negative output terminal
