Instruction Manual for AS380 Series Elevator Integrated Drive Controller
46
R/L1
Main circuit AC power input, three-phase input power
supply connected.
S/L2
T/L3
U/T1
Integrated drive controller output, three phase
synchronous/asynchronous motor connected.
V/T2
W/T3
4.4.3 Main circuit wire specification
The conductor is 600V copper-core plastic insulation conductor for power supply. See Table 4.2
for conductor specification and fastening torque.
Table 4.2 conductor specification and fastening torque
Model AS380-
Connectable wire
specification（mm
2
）
Recommended wire
specification（mm
2
）
Fastening
torque（N.m）
2S01P1 2～6 2.5 1.5
2S02P2 2～6 4 1.5
2S03P7 2～6 4 1.5
4T02P2 2～6 4 1.5
4T03P7 2～6 4 1.5
4T05P5 2～6 4 1.5
4T07P5 4～8 6 2.5
4T0011 4～8 6 2.5
4T0015 4～8 6 2.5
4T18P5 8～16 16 4.0
4T0022 8～16 16 4.0
4T0030 14～25 25 9
4T0037 35～100 35 9
4T0045 35～100 50 9.0
4T0055 60～100 60 18.0
4T0075 80～125 80 18.0
