Instruction Manual for AS380 Series Elevator Integrated Drive Controller
47
Important
Wire specification is decided in accordance with the conditions of surrounding temperature
50℃ and wire temperature allowable 75℃
The main circuit of integrated drive control adopted the open terminals; round crimping
terminal should be used for the open terminals. Please check the table 4.3 for the round crimping
terminal.
Table 4.3 round crimping terminal
Wire cross-section（mm
2
） Terminal screw specification
Round crimping terminal
specification
0.5
M3.5 1.25/3.5
M4 1.25/4
0.75
M3.5 1.25/3.5
M4 1.25/4
1.25
M3.5 1.25/3.5
M4 1.25/4
2
M3.5 2/3.5
M4 2/4
M5 2/5
M6 2/6
M8 2/8
3.5/5.5
M4 5.5/4
M5 5.5/5
M6 5.5/6
M8 5.5/8
8
M5 8/5
M6 8/6
M8 8/8
14
M6 14/6
M8 14/8
22
M6 22/6
M8 22/8
