Steren COM-820 User Manual

To add IP & MAC Binding entries:
1. Click the Add New.. button.
2. Enter the MAC Address and IP Address.
3. Select the Bind checkbox.
4. Click the Save button to save it.
To modify or delete an existing entry:
1. Find the desired entry in the table.
2. Click Modify or Delete as desired on the Modify column.
To fi nd an existing entry:
1. Click the Find button.
2. Enter the MAC Address or IP Address.
3. Enter the Find button in the next page.
Click the Enable All button to make all entries enabled.
Click the Delete All button to delete all entries.
ARP LIST
To manage the computer, you could observe the computers in
the LAN by checking the relationship of MAC address and IP
address on the ARP list, and you could confi gure the items on
the ARP list also. This page displays the ARP List; it shows all
the existing IP & MAC Binding entries.
ENGLISH
ENGLISH-63

Steren COM-820 Specifications

General

Brand	Steren
Model	COM-820
Category	Network Router
Language	English
