Site Specifications Operator Manual T6800 Rev B
SYSTEM 1 endo Liquid Chemical Sterilant Processing System
2-1
SITE SPECIFICATIONS
2
Water Requirements*:
Pressure: Minimum 40 psig (276 kPa), Preferred 50 - 60 psig (345 - 414 kPa), maximum
90 psig (620 kPa)
Flow Rate: Minimum 2.5 gpm (9.5 Lpm)
Temperature: 109 -140°F (43 - 60°C)
Recommended: For optimum cycle time, water temperature should be between 115 - 118°F
(46 - 48°C)
Supply Line Size: 1/2” (1.27 cm) I.D. minimum / 3/4” (1.9 cm) I.D. optimum
Connection: 3/4” (1.9 cm) male hose connector
Quality: Potable/Tap water, ≤ 140 ppm hardness as CaCO
3
Drain: 1 1/4” (3.18 cm) I.D. (minimum) non-back pressuring drain
Water usage: Approximately 8.7 gal. (33 L) per processing cycle
Space and Weight Requirements:
SYSTEM 1 endo Processor
Width: 40” (102 cm.)
Depth: 24” (61 cm.)
Height: 38” (97 cm.) (includes overhead clearance)
Weight: 136 lbs. (62 kg.)
Operating Weight: 162 lbs. (74 kg.)
Electrical Requirements:
Specifications: 115 VAC, 60 Hz, 15 A
Service: 115 VAC, 20 A, 60 Hz dedicated circuit
Hospital grade GFCI duplex receptacle
WARNING: The SYSTEM 1 endo Processor must be installed by qualified personnel and according to
correct national and local electrical safety codes. Failure to do so can result in shock hazard that could
endanger the health of the operator.
NOTE: There are no special requirements for venting the drain.
WARNING: Do not position equipment so that it is difficult to disconnect the plug from the duplex
receptacle.
WARNING: Connect the SYSTEM 1 endo Processor to hospital grade receptacle only following national and
local codes (GFCI, RCBO, etc.).
NOTE: Back flow (back siphonage) prevention provided by user (check local codes).
* Potable water should meet specifications identified in AAMI TIR 34: Water for the Reprocessing of Medical Devices.
Failure to meet these specifications may result in cancelled cycles and require the installation of additional water
treatment solutions by the health care facility.
