Steris SYSTEM 1 endo User Manual

Component Identification Operator Manual T6800 Rev B
SYSTEM 1 endo Liquid Chemical Sterilant Processing System
4-5
IMPORTANT:
These instructions are to be placed in an easily seen location.
COMPONENTS OF THE SYSTEM 1 endo PROCESSOR
Refer to the illustrations of the Processor at the beginning of this section.
Pre-filter Assembly
The Pre-filter Assembly is an integral component of the system. The Pre-filter
Assembly is comprised of a regulator, filter housing, and two pre-filters, A and B.
CONTROLS FOR THE SYSTEM 1 endo PROCESSOR
Control Panel
The control panel features:
• a display window
• touch-sensitive touch pads
• a printer
Display Window
The 16-character x 2-line display window shows cycle information and allows
the operator to view option selections.
Touch Pads
Cycle touch pads include: START, DIAG, CANCEL, and STATUS.
• Press the START touch pad to initiate a liquid chemical sterilization cycle.
• Press the DIAG touch pad to initiate a DIAGNOSTIC cycle.
• Press the CANCEL touch pad twice within 8 seconds to cancel a cycle
or once at the end of the cycle to release the door seal.
• Press the STATUS touch pad to display the cycle phase while the unit
is in-cycle.
Part 2:
SYSTEM 1 endo
Processor
WARNING: Devices are not
liquid chemically sterilized
and/or adequately rinsed
when a liquid chemical
sterilization cycle is
cancelled.
WARNING: The SYSTEM 1
endo Processor may be
used only in hospital-grade
rooms when it is installed
according to the applicable
specification (VDE 0107,
Class 1 Group C NFPA
Rating).
WARNING: The SYSTEM 1
endo Processor is not
intended for operation
in explosion-endangered
areas.
WARNING: Danger: Risk
of explosion if used in the
presence of flammable
substances.
